| Specifications | KMX-100 |
| Capacity | 120g |
| Repeatability | (Std Dev) (g) 0.3% (3g sample),0.2% (10g sample),0.2% (3g sample),0.05% (10g sample) |
| Readability | 0.1% / 0.01g 0.05% / 0.005g |
| Sample Size | 3g to 20g typical, 0.5g min. |
| Interface Bidirectional | RS-232 |
| Timer | 1 – 99 minutes, 30-second increments to 60 minutes |
| Heating Technology | Infrared (no glass) Halogen |
| Temperature Range | 50°C to 160°C in 5° increments |
| Power | 100 to 240 VAC, 50/60 Hz |
| Tare | Range To capacity by subtraction |
| Operating Temperature | Range 5° to 40°C |
| Display Type | Custom backlit LCD |
| Displays | % moisture or % solids or weight (g), temperature, time |
| Pan Size (Diameter) | 90 mm |
| Dimensions (W x H x D) | 17 x 13 x 28 cm |
| Net Weight | 2.3 kg |
| Shipping Weight | 3.9 kg |
| Included Accessories | Sample Pans (Quantity 50) Standard |
| In Use Cover Standard | Sample Pan Handler Optional (PN 11113873) Standard |
| Certificates | ISO & CE Approved |
